TPU (Thermoplastic Polyurethanes) hot melt adhesive film is a functional film made of thermoplastic polyurethane as the main raw material. Polyurethane is environmentally friendly, non-toxic and odorless. Compared with other types of adhesive films, it is characterized by good stretchability and resilience, which is very suitable for Bonding of fabrics and leather that require elasticity.
TPU hot melt adhesive film (with paper/without paper) | |||||
Product code | ZPMT-film001 | ZPMT-film002 | ZPMT-film003 | ZPMT-film004 | ZPMT-film005 |
Supply form | film | film | film | film | Film (non-yellowing) |
Thickness (mm) |
0.02-0.2 | 0.02-0.2 | 0.02-0.2 | 0.02-0.2 | 0.02-0.2 |
Width (mm) |
5-1600 | 5-1600 | 5-1600 | 5-1600 | 5-1600 |
Melting point ( ℃ ) |
60 | 80 | 85 | 110 | 110 |
Bond strength (N/5cm 2 ) |
>10 | >10 | >15 | >15 | >15 |
Washability (40℃) |
* | ** | ** | *** | *** |
Washability (60℃) |
— | — | — | ** | ** |
Dry cleaning resistance (℃) |
— | — | — | — | — |
Pressing temperature (℃) |
80-90 | 100-110 | 110-120 | 130-140 | 130-140 |
Pressing time (S) |
15-20 | 15-20 | 15-20 | 15-20 | 15-20 |
Pressure(kgf/cm 2 ) | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 |
Applicable to | Suitable for conductive cloth, conductive foam, PVC plastic, plastic-coated cloth, waterproof three-layer tape, seamless underwear, seamless pockets, waterproof zippers, waterproof strips, sewing-free shoe materials, multi-functional clothing, reflective materials, nylon Fabrics, polyester fabrics, Lycra elastic fabrics, elastic fabrics, PVC, leather, PET and other materials: main application areas: electronic shielding materials, car interior daily necessities, seamless underwear and swimsuits, dry cleaning men's and women's high-end suits and seamless shoe materials, etc. | ||||
Note: The pressing conditions are for reference only and are related to the pressing equipment, thickness of the bonded material, and pressure. Users need to confirm experimentally according to specific conditions. | |||||
***: Very good **: Good *: OK —: Not recommended NO: No data |
