PA hot melt web film, conventional hot melt adhesive web film TPU, EVA, PES, PA, weight 10-120g per square meter, door width 6-1600 cm, can meet the secondary compounding process requirements of downstream customers. Common applications: interlining, home textiles, fabric lamination.
PA hot melt adhesive web with/without paper | |||||
Product code | ZPMA-web001 | ZPMA-web003 | ZPMA-web004 | ZPMA-WP001 | ZPMA-WP003 |
Supply form | mesh | mesh | mesh | Roll paper with paper backing | Roll paper with paper backing |
Gram weight (g/m 2 ) | 8-700 | 8-700 | 8-700 | 10-35 | 10-35 |
Width (mm) | 5-1650 | 5-1650 | 5-1650 | 5-1120 | 5-1120 |
Melting point range ( °C ) | 115-125 | 105-110 | 125-135 | 115-125 | 105-110 |
Bonding strength (N/5cm 2 ) | >20 | >20 | >20 | >20 | >20 |
Washing resistance (40°C) | ** | ** | *** | ** | ** |
Washing resistance (60°C) | — | — | *** | — | — |
Dry cleaning resistance (°C) |
*** | *** | *** | *** | *** |
Hot pressing temperature (°C) |
130-140 | 110-115 | 135-160 | 130-140 | 110-115 |
Pressing time (S) | 15-20 | 15-20 | 15-20 | 15-20 | 15-20 |
Pressure (kgf/cm 2 ) | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 |
Recommended objects | Universal product, suitable for EM embroidery badges, trademarks, non-woven fabrics, leather. The main application areas are high-end clothing and clothing accessories. | ||||
Note: The above hot pressing conditions are for reference only, which are also connected with the hot press machine and require the thickness and pressure of the bonded material. Consumers need to conduct testing and confirmation based on specific circumstances. | |||||
***: Very good **: Good *: OK —: Not recommended NO: No data |
